14-Row Sunflower Harvesting Table with Crushers FREESUN 960

14-Row Sunflower Harvesting Table with Crushers FREESUN 960

We harvest sunflower heads for oil and snacks directly in the field.

Color options

Body Color Options
C01
D01
J01
F01
E01
E02
E03
E04
E05
  • Description
  • Features
  • Options
  • Upload information
  • Get Information

It harvests sunflower heads for snack and oil production directly in the field.

It reduces the need for manual labor during sunflower harvesting and ensures a quick harvest without being affected by weather conditions.

It is designed to be easily adapted to fit any brand and model of combine harvester with a simple modification to the mounting kit.

The superior harvesting performance demonstrates the necessity of the Elibol Sunflower Harvesting Table.

It delivers superior performance across all sunflower varieties and operates seamlessly on all crops, regardless of the size of the sunflower stalks and heads.

Serving as a prime example of agricultural mechanization, the sunflower harvesting table will be the top choice for harvesting operations due to its high performance.

The combination of ideal design and machine specifications is a key criterion for success.

Designed in this way, the Elibol Sunflower Harvesting Table aims to maintain high performance, enabling you to harvest crops easily and without loss.

MODEL FREESUN 960
ROW COUNT 14
ROW SPACING INDEPENDENT
DEFLECTOR TRAY COUNT (PCS) 41
WORKING WIDTH (MM) 9600
TOTAL WIDTH (MM) 10050
TRANSPORT WIDTH (MM) 10050
HARVEST POSITION TOTAL LENGTH (MM) 2400
LOADING POSITION (FOLDED) TOTAL LENGTH (MM) 2670
TOTAL HEIGHT (MM) 1400
DRY WEIGHT WITHOUT CHOPPER (KG) 2900
DRY WEIGHT WITH CHOPPER (KG) 4000
POWER SOURCE COMBINE HARVESTER DRIVEN
DRIVE SHAFT SPEED (RPM) 450/750
RECOMMENDED WORKING SPEED (KM/H) (WITHOUT STALK CHOPPER) 6-8 KM/H
RECOMMENDED WORKING SPEED (KM/H) (WITH STALK CHOPPER) 4-6 KM/H
PERMITTED WORKING TEMPERATURE (°C) -20/40
NOISE LEVEL 80 DB
CONTINUOUS WORKING TIME 8 H
CHOPPER DISTANCE CONTROL HYDRAULIC
CHOPPER SPEED (RPM) 1960/2080
CHOPPER UNIT COUNT (PCS) 14
CHOPPER BLADE COUNT (PCS) 28
BLADE HARDNESS 60 HRC
Color options
Body Color Options
C01
D01
J01
F01
E01
E02
E03
E04
E05
MODEL / VEHICLE 13.60 TRUCK 8.10 MID-AXLE TRUCK 7.10 TRUCK 20' DRY 40' DRY 40' HIGH CUBE
FREESUN 960 WITH CHOPPER 2 - - - 1 1
FREESUN 960 WITHOUT CHOPPER 2 - - - 1 1
